Photo for reference only Contact us for more images


EXSHINE Part Number:EX-MC56F8167VPYE
Manufacturer Part Number:MC56F8167VPYE
Manufacturer / Brand:NXP Semiconductors / Freescale
Brief Description:IC MCU 16BIT 512KB FLASH 160LQFP
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Condition:New and unused, Original
Datasheet Download:MC56F8167/8367
Alternative Replacement:-
Real Time Availability for
In stock: 31300 pcs can ship in 1-2 days.
Future Stock: 12000 pcs in 7-10 days.
Manufacturer Lead time: 8-10 Weeks

Click below to order MC56F8167VPYE online

US$ 27.406

Reference Marketing Price: US$ 27.406

Our Best Price: N/A (Email us)



  • Description
  • Payment
  • Shipping
  • Packaging

Product Parameter

Voltage - Supply (Vcc/Vdd) 2.25 V ~ 3.6 V
Supplier Device Package 160-LQFP (24x24)
Speed 40MHz
Series 56F8xxx
RAM Size 16K x 16
Program Memory Type FLASH
Program Memory Size 512KB (256K x 16)
Peripherals POR, PWM, WDT
Packaging Tray
Package / Case 160-LQFP
Other Names 935309348557
Oscillator Type External
Operating Temperature -40°C ~ 105°C (TA)
Number of I/O 76
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Manufacturer Standard Lead Time 10 Weeks
Manufacturer Part Number MC56F8167VPYE
Expanded Description 56800E 56F8xxx Microcontroller IC 16-Bit 40MHz 512KB (256K x 16) FLASH 160-LQFP (24x24)
Description IC MCU 16BIT 512KB FLASH 160LQFP
Data Converters A/D 16x12b
Core Size 16-Bit
Core Processor 56800E
Connectivity EBI/EMI, SCI, SPI


Standard Package 40
Other Names 935309348557

You can choose the below payment options. Please contact our sales team if you have any questions.

 T/T (Bank Transfer)
 Receiving: 1-4 days.

 Receiving: immediately.

 Western Union
 Receiving: 1-2 hours.

 Receiving: 1-2 hours.

 Receiving: immediately.

You can choose the below shipping options, contact our sales team to check the shipping cost to your address.
If you don't want to use our shipping service, you can also arrange pick up from our warehouse or ship by your courier account.

 Delivery time: 1-3 days.
 Delivery time: 1-3 days.
 Delivery time: 2-4 days.
 Delivery time: 3-6 days.
 Delivery time: 7-10 days.

Distributor of NXP USA Inc.

- NXP Semiconductors enables secure connections and infrastructure for a smarter world, advancing solutions that make lives easier, better and safer. As the world leader in secure connectivity solutions for embedded applications, NXP is driving innovation in the secure connected vehicle, end-to-end security & privacy and smart connected solutions markets. Built on more than 60 years of combined experience and expertise, the company has 45,000 employees in more than 35 countries.
Freescale Semiconductor has been acquired by NXP Semiconductor. Freescale Semiconductor parts are now a part of the NXP family (Dec 2015).

The NXP Standard Products Division’s portfolio (Discretes, Logic & MOSFETs) has been transferred to Nexperia (Feb 7, 2017).
The NXP Bi-Polar Division product portfolio (Diodes, Thyristors & Transistors) has been transferred to WeEn Semiconductors (Jan 19, 2017).
The NXP RF Power Division’s product portfolio ( RF Amplifiers, RF MOSFETs) has been transferred to Ampleon (October 5, 2105).
